The NXI-6110-8 is a high-accuracy data acquisition module with 8 channels. It can collect analog signals up to ±60V at 100KS/s with0.2mV accuracy. When used with external DC high voltage dividers and current sensors, it can collect signals up to 2kV and ±1000Afor DC power measurement. Its wide measurement range, high sampling rate, and strong integration and scalability make it suitablefor high-voltage battery pack testing, photovoltaic inverters, HIL testing systems, etc.
Main Features
- Range: ±60V, ±10V, ±6V, ±1V, ±200mV8 isolated analog input channels
- Up to 100KS/s per channel
- Compatible with DC high-voltage dividers and current sensors (optional)
- Max. measurable voltage: 2000V; Max. measurable current: ±1000A
- High isolation voltage: DC 1500 V (CAT II) between output and ground
- Trigger function for multi-channel synchronous collection
- Compatible with the NXI data acquisition and measurement system
- Internal/external clock source selectable
- Acquisition memory capacity: 4MB*8
- Single module with single slot, applicable to NXI-F1000 chassis or independent use
- Support 12V DC power supply, LAN/CAN communication for individual control
- Support Modbus-RTU, SCPI, CANopen protocols
Application Fields
